Beretta Cheetah
TypeSemi-automatic pistol
Place of originItaly
Production history
ManufacturerBeretta
Produced1976–2017
Specifications
Mass
  • 81FS: 685 gm/24 oz
  • 82FS: 630 gm/22 oz
  • 83FS: 640 gm/23 oz
  • 84FS: 660 gm/23 oz
  • 85FS: 620 gm/22 oz
  • 86FS: 660 gm/23 oz
  • 87BB: 570 gm/20 oz
  • 87 Target: 835 gm/29 oz
  • 89: 1160 gm/41 oz
Length
  • 172 mm/6.77 in: 81, 82, 84, 85, 87
  • 177 mm/6.97 in: 83
  • 185 mm/7.28 in: 86
  • 225 mm/8.86 in.: 87 Target
  • 240 mm/9/45 in: 89
Barrel length
  • 97 mm/3.82 in: 81, 82, 84, 85, 87
  • 102 mm/4.02 in: 83
  • 111 mm/4.37 in: 86
  • 150 mm/5.91 in: 87 Target
  • 152 mm/5.98 in: 89
Cartridge
  • .32 ACP: 81, 82
  • .380 ACP: 83, 84, 85, 86
  • .22 LR: 87, 87 Target, 89
ActionBlowback
Feed systemMagazine of capacity;
  • 7 rounds: 83
  • 8 rounds: 85, 86, 87, 89
  • 9 rounds: 82
  • 10 rounds: 87 Target
  • 12 rounds: 81
  • 13 rounds: 84

The Beretta Cheetah, also known by its original model name of 'Series 81', is a line of compact blowback operated semi-automatic pistols designed and manufactured by Beretta of Italy. They were introduced in 1976 and include models in .32 ACP (Models 81 and 82), .380 ACP (9 mm Short) (Models 83, 84, 85 and 86) and .22 LR (Models 87, 87 Target and 89). Beretta has discontinued the manufacture of certain models and versions, but Cheetah pistols in .22 LR, .32 ACP and .380 ACP are still being manufactured and sold.[1]

  • 1Models
  • 2Versions
Beretta 84bb owners manual 2017

Beretta APX Pistol and Sako TRG M10 Schematics and Parts Listings are now available. If you don't have Adobe Acrobat Reader, you'll need to install it to view and print your manuals and product information. Our Beretta Chevrolet workshop manuals contain in-depth maintenance, service and repair information. Get your eManual now!

Models[edit]

81 and 82[edit]

These two models are chambered for the .32 ACP cartridge. The 81 has a double stacked magazine with 12 round capacity, while the 82 has a single stacked magazine with nine round capacity and resultant thinner grips.

83, 84 and 85[edit]

Manual

These three models[2] are chambered for the .380 ACP (9 mm Short) cartridge. The 84 has a double stacked magazine with 13 round capacity, while the 83 and 85 have a single stacked magazine with seven and eight round capacity respectively, and resultant thinner grips. The 84 and 85 have a 3.81' barrel, while the 83 has a 4' barrel.

86[edit]

The model 86 is chambered for the .380 ACP (9 mm Short) cartridge, but differs significantly from other models in the series, because it has a redesigned front end with a tip-up barrel that hinges at the muzzle to open the breech. This allows the shooter to load a cartridge directly into the chamber, and not have to operate the slide.

87[edit]

There are two distinct 87 models both chambered for .22 LR. The standard model is similar to other models, but the 87 Target has a longer barrel and slide, can accept optical sights, and is single action only.

Beretta 84bb Owners Manual

89[edit]

The model 89[3] is also chambered for the .22 LR and is designed for competition and range training, with a lightweight frame and ergonomic grips.

Versions[edit]

Beretta Model 84bb Reviews

There are potentially five versions for models 81 through 87. The features for each version in models 81, 82, 84 and 85 are consistent between models (i.e., the 81FS, 82FS, 84FS and 85FS all have similar features). This is not the case with models 83, 86, 87 and 89, which were not made in all versions.

Base versions (no letter suffix)[edit]

Base versions of models 81 through 87 are noted for having a rounded trigger guard and generally fewer safety features than subsequent versions. Safety is ambidextrous and frame-mounted. The frame is alloy, the slide is blued steel and the standard grips are wood.

B versions[edit]

The B versions of models 81, 82, 84, and 85 introduced an automatic firing pin safety, a shorter extractor and grooved front and back straps.

BB versions[edit]

The BB versions of models 81, 82, 84 and 85 have more serrations on the slide, white dot and post sights and other subtle changes.

F versions[edit]

The F versions of models 81, 82, 84 and 85 introduced the 'combat' trigger guard with a squared-off front that allows for a finger hold, plastic grips, a proprietary 'Bruniton' finish, a chrome-plated barrel and chamber, and a combination safety and decocker lever.

FS versions[edit]

Current production models of .32 ACP and .380 ACP Cheetah pistols are in the FS configuration (e.g. 81FS).[4] In models 81, 82, 84 and 85 they include internal improvements over the F versions that are not visible during casual inspection.[further explanation needed]

Recently (2014-2015) the 81FS, 84fs and 85fs models have been available new for sale in the U.S. They are occasionally available in both the Bruniton and nickel finishes.

Browning BDA 380 & FN 140 DA[edit]

From 1977 to 1997 Beretta built the Browning BDA 380, which is essentially the model 84BB with a standard ejection port (instead of an open slide), a slide-mounted decocker/safety and a spur hammer. Production resumed in 2000 and continues through today (2015). During both periods mentioned Beretta also made the FN 140 DA, which is identical to the BDA 380 except for being marked 'Fabrique Nationale' instead of 'Browning'. The 140 DA was also made in a .32 ACP version.

Users[edit]

  • Algeria[5]
  • Italy
  • Kazakhstan - since 2007 used as service pistol in private security companies[6]
  • Slovenia
  • Venezuela
  • Namibia

Gallery[edit]

Owners Manual Toyota

  • The Beretta 82BB.

  • The Beretta 84FS.

  • The Beretta 84FS disassembled.

  • The Beretta 87 Target.

Notes[edit]

  1. ^'SERIE 80'. www.beretta.com. Retrieved 20 April 2018.
  2. ^'81 Series (Cheetahs) semi-auto Owner's Manual'. gunownersresource.com. Retrieved 20 April 2018.
  3. ^http://pdf.textfiles.com/manuals/FIREARMS/beretta_89.pdf
  4. ^'Archived copy'. Archived from the original on 2011-07-06. Retrieved 2011-07-02.CS1 maint: archived copy as title (link)
  5. ^'World Infantry Weapons: Algeria'. 2015. Archived from the original on 24 November 2016. Retrieved 7 June 2019.
  6. ^'Регистрационный номер: 3.1/003 Пистолет служебный BERETTA - 84'
    Постановление Правительства Республики Казахстан № 1305 от 28 декабря 2006 года 'Об утверждении Государственного кадастра гражданского и служебного оружия и патронов к нему на 2007 год'

External links[edit]

  • Beretta 89 Instruction Manual in English

Beretta 84 Cheetah Owners Manual

Wikimedia Commons has media related to Beretta Cheetah.
